Product Details:
|
Application: | Clinical/ Hospital/ Laboratory | Country Of Origin: | China |
---|---|---|---|
Capacity(ml): | 0.1~300 | Single Ultrasound Time(min): | 0.1~99.9 |
Operation Mode: | 20 /38/40mm | Ultrasound Frequency(kHz): | 30 |
Standard Horn(mm): | Φ6 | Optional Horn(mm): | Φ1.5/2/3/6/8 |
Horn Material: | TC4 Titanium Alloy | ||
Highlight: | High Speed Homogenizer Mixer,Laboratory High Shear Homogenizer,High Shear Homogenizer Mixer |
1. Use high-quality motors, stable operation, lower noise, long-term operation, safe and reliable design.
2. All parts of the working head contacting materials are made of high-quality stainless steel with good corrosion resistance.
3. The working head is connected with the drive motor by a coupling, which is easy to disassemble and assemble.
4. The speed control frame with step less speed governor, which is convenient for speed control and stable operation.
Technical parameters
Model | HR-500 |
Rotary Speed | 10000-31000r/min |
Capacity | 0.2-7000ml (H2O) |
Standard Head | 25G |
Input Power | 500W |
Output Power | 320W |
Rotary Speed Display | Graduate Display |
Speed Mode | Gear speed regulation |
Head Material | 316L Stainless steel |
Bearings Material | PTEE |
proper temperature | ≤120C° |
Allowable ambient temperature | 5-40C° |
Allowable relative humidity | 80% |
Process type | Micro batch processing |
Host net Weight | 3kg |
Power supply | AC 220V 50~60HZ |
Host size (length x diameter) | 275×φ65mm |
Host packing size | 470×340×205mm |
Host GW |
4kg |
